Water transfer plan from Haftian spring to Tafresh city and villages along the way

1580823795_haftian 90-130
1580822464_2
1580822485_3
1580823795_haftian 90-130
1580822464_2
1580822485_3

Client: Markazi Province Regional Water Company

Contract Start Date: 2010-10-23

Brief description:

According to the above contract, the technical services and studies related to the second phase of the water transfer project from Chesme Haftian to the city of Tafresh and a number of villages along the route were entrusted to these consulting engineers.

The location of this project is the Chesme Haftian pumping station, which has 155 kilometers of main and branch transmission lines with diameters of 63 to 800 mm, 8 pumping stations, 28 reservoirs, and a maximum daily flow rate of 150 liters per second.

Project Technical Specifications:



  • Project horizon population: 48068 people
  • Maximum daily flow rate: 170 liters per second
  • Transmission line length: 155 km
  • Main and branch pipe diameters: 800, 600, 500 and 400, 125, 110, 90, 75, 63 mm
  • Main pipe material: steel and polyethylene
  • Number of pumping stations: 8
  • Volume and number of tanks: about 11,000 cubic meters and 28 heads
